Max cutting depth:400mm
Free speed:2200rpm
Air consumption:3.5m³/min
Noise level:105dB(A)
Application:
Used for cutting of concrete, rock, coal. Designed for emergency rescue, road repairs and wall breaking and other heavy operations.
Features:
● Automatic trigger switch:
Use automatic trigger switch to ensure the safety of operation;
● Ergonomic hand grip design:
Low vibration, and minimize operator's fatigue;
● Portable design:
One-man operation, powerful ,efficient;
● Equipped with water injection cooling device, dust free and anti sparking;
● Pneumatic motor:
No sparkles during operation and used in explosive and flammable environment;
● Emergency rescuing:
Pneumatic Circular Saw is suitably used in emergency rescue;
● Different available saw blades:
Various saw blades for cutting different materials;
● Various sizes of saw blades:
Max Dia.400mm achieves the deepest and width cutting capacity.
Specifications
Product Name | Trolley-Type Pneumatic Circular Saw | |
Manufacture Model | CS22-180 | CS22-400 |
MA No. | JQP-18 | JQP-18 |
Max. cutting depth (mm) | 180 | 400 |
Max. cutting width (mm) | 500 | 800 |
Power (kw) | 5 | 5 |
No-load speed (rpm) | 2900 | 2200 |
Working pressure (Mpa) | 0.6 | 0.6 |
Air Consumption (m3/min) | 3.5 | 3.5 |
Type of drive | Gearbox | Gearbox |
Noise level dB(A) | 105 | 105 |
Vibration Level(m/s²) | <2.5 | <2.5 |
Weight(kg) | 52 | 95 |
Package:
Standard Kit: Circular Saw + Saw blade + Installation tools + Tool case
Circular saw accessories: Saw blade
Nonmetal alloy saw blades:
Used for cutting nonmetal material, belt pulley, plastic, wood and more.
Alloy saw blades:
Used for steel, aluminum, copper, iron, belt with steel wire mesh, and more.
Diamond saw blades:
Used for cutting concrete, tough diamond blades, and concrete with steel.
Carborundum saw blades:
Used for concrete, stone, cast iron material application.
Diamond saw blade:
Used for high hardness or reinforced concrete
Matched models of saw blades | ||||||
Model of Matched Equipment | Saw blade | Ordinary Saw Blades | Alloy Saw Blades | Diamond Saw Blades | Carborundum Saw Blades | Hard Diamond Saw Blades |
Model | Dia. | Model | Model | Model | Model | Model |
CS21-030 | 100mm | CS810-10 | CS811-10 | CS812-10 | CS813-10 | CS814-10 |
CS21-065 | 190mm | CS810-19 | CS811-19 | CS812-19 | CS813-19 | CS814-19 |
CS21-085 | 230mm | CS810-23 | CS811-23 | CS812-23 | CS813-23 | CS814-23 |
CS21-100 | 300mm | CS810-30 | CS811-30 | CS812-30 | CS813-30 | CS814-30 |
CS21-120 | 350mm | CS810-35 | CS811-35 | CS812-35 | CS813-35 | CS814-35 |
CS21-180 | 400mm | CS810-40 | CS811-40 | CS812-40 | CS813-40 | CS814-40 |
CS22-180 | 450mm | CS810-45 | CS811-45 | CS812-45 | CS813-45 | CS814-45 |
CS22-400 | 1000mm | CS810-100 | CS811-100 | CS812-100 | CS813-100 | CS814-100 |
